Pro-Flex
Pro-Flex Special Termination Plate with Direct Connect Valve
- Availability:
- Usually Ships in 5-7 Business Days
- Weight:
- 0.00 LBS
Description
Pro-Flex Special Termination Plate with Direct Connect Valve
Pro-Flex Special Termination Plates with Direct Connect Valve combine a supported CSST termination point with an integrated gas shutoff valve. Designed for Pro-Flex gas piping installations, these assemblies provide a compact transition from flexible CSST tubing directly to a valve at appliance, equipment, and finished-wall connection locations.
Available for 1/2" and 3/4" Pro-Flex CSST, the Pro-Flex product guide identifies PFVT-1206 and PFVT-3406 as Special Termination Plates with Direct Connect Valve.
Product Highlights
- Special termination plate with integrated direct-connect gas valve
- Designed for Pro-Flex CSST gas piping installations
- Available for 1/2" and 3/4" tube sizes
- Combines the termination plate and valve into one assembly
- Provides a supported CSST termination point
- Creates an accessible gas shutoff location
- Useful for appliance and equipment gas piping rough-ins
- Helps simplify CSST-to-valve transitions
- Available as Pro-Flex part numbers PFVT-1206 and PFVT-3406
Available Models
| Part Number | Tube Size | Description |
|---|---|---|
| PFVT-1206 | 1/2" | Special Term Plate with Direct Connect Valve |
| PFVT-3406 | 3/4" | Special Term Plate with Direct Connect Valve |
Technical Specifications
| Manufacturer | Pro-Flex |
|---|---|
| Product Type | Termination Plate with Direct Connect Valve |
| Compatible Piping System | Pro-Flex CSST |
| Available Tube Sizes | 1/2" and 3/4" |
| PFVT-1206 Tube Size | 1/2" |
| PFVT-3406 Tube Size | 3/4" |
| Valve Configuration | Direct Connect Valve |
| Mounting Configuration | Special Termination Plate |
| Primary Application | Supported CSST Termination with Integrated Gas Shutoff Valve |
What Is a Termination Plate with Direct Connect Valve?
A termination plate with direct connect valve combines two functions into a single gas piping component. The termination plate provides a supported mounting point for the Pro-Flex CSST connection, while the integrated valve provides a gas shutoff directly at the termination location.
This arrangement can simplify installations where a CSST run terminates near an appliance or piece of gas-fired equipment and an accessible shutoff valve is required.
Because the valve is integrated into the termination assembly, fewer separate transition components may be required compared with building the termination and valve arrangement from individual parts.
Why Use a Direct Connect Termination Valve?
Integrated Termination
- Combines mounting plate and valve in one assembly
- Provides a defined termination point for Pro-Flex CSST
- Supports the connection at the rough-in location
- Helps organize finished gas piping installations
- Reduces the need to assemble separate termination components
Accessible Gas Shutoff
- Valve is located directly at the termination point
- Provides convenient gas-flow control
- Useful for appliance and equipment connections
- Suitable for accessible finished-wall rough-ins
- Available for two common Pro-Flex CSST sizes
Available Sizes
PFVT-1206 – 1/2"
The PFVT-1206 is designed for 1/2" Pro-Flex CSST and combines a special termination plate with an integrated direct connect valve.
PFVT-3406 – 3/4"
The PFVT-3406 is designed for 3/4" Pro-Flex CSST and combines a special termination plate with an integrated direct connect valve.
Common Applications
Appliance Connections
- Gas ranges and cooktops
- Water heaters
- Gas dryers
- Fireplaces
- Other compatible gas-fired appliances
Gas Piping Rough-Ins
- Pro-Flex CSST termination points
- Finished-wall gas connections
- Equipment gas shutoff locations
- Residential gas piping systems
- Light-commercial gas piping installations
Direct Connect Valve vs. Separate Termination Fitting
Direct Connect Valve
- Valve incorporated into the termination assembly
- Provides shutoff directly at the CSST termination
- Compact installation configuration
- Fewer separate components at the connection point
- Available as PFVT-1206 and PFVT-3406
Termination Plate with Fitting
- Provides a supported threaded termination
- Separate valve can be added where required
- Useful when a particular downstream valve configuration is specified
- Provides additional flexibility in component selection
- Available in other Pro-Flex termination-plate configurations
Choosing the Correct Model
| Part Number | CSST Size | Configuration |
|---|---|---|
| PFVT-1206 | 1/2" | Special Termination Plate with Direct Connect Valve |
| PFVT-3406 | 3/4" | Special Termination Plate with Direct Connect Valve |
Pro-Flex CSST System Compatibility
The Pro-Flex product guide lists PFVT-1206 and PFVT-3406 under Termination Plates with Direct Connect Valve. PFVT-1206 is identified for 1/2" tubing and PFVT-3406 for 3/4" tubing.
Select the termination assembly that matches the nominal Pro-Flex CSST size being installed and verify compatibility with all connected piping and appliance components.
Installation Considerations
- Select the model that matches the Pro-Flex CSST tube size.
- Verify the downstream appliance or equipment connection requirements.
- Secure the termination plate to an appropriate mounting surface.
- Position the valve where it will remain accessible after installation.
- Use compatible Pro-Flex tubing, fittings, and installation components.
- Follow current Pro-Flex CSST fitting assembly instructions.
- Properly support connected piping and equipment.
- Protect CSST against physical damage where required.
- Leak-test completed gas piping connections according to applicable requirements.
- Follow applicable fuel-gas codes and local installation requirements.
- Installation should be completed by qualified gas-piping personnel.
Need Help Selecting a Pro-Flex Termination Valve?
Our industrial PVF specialists can help review your Pro-Flex CSST size, appliance connection, termination configuration, and gas shutoff requirements before you order.
Frequently Asked Questions
What is a Pro-Flex termination plate with direct connect valve?
It combines a supported Pro-Flex CSST termination plate with an integrated gas shutoff valve at the connection point.
What size is PFVT-1206?
PFVT-1206 is the 1/2" Special Termination Plate with Direct Connect Valve.
What size is PFVT-3406?
PFVT-3406 is the 3/4" Special Termination Plate with Direct Connect Valve.
What sizes are available?
The listed models are available for 1/2" and 3/4" Pro-Flex CSST.
Does the termination plate include the valve?
Yes. These models are identified by Pro-Flex as Special Termination Plates with Direct Connect Valve.
Why use a termination plate with an integrated valve?
The integrated configuration combines a supported CSST termination and gas shutoff valve into one assembly, simplifying compatible appliance and equipment rough-ins.
Can this be used as an appliance gas shutoff?
The assembly incorporates a gas valve at the termination point. The installed location and valve accessibility should comply with current manufacturer instructions and applicable codes.
How do I choose between PFVT-1206 and PFVT-3406?
Select PFVT-1206 for 1/2" Pro-Flex CSST or PFVT-3406 for 3/4" Pro-Flex CSST.
Who should install Pro-Flex termination valves?
CSST and gas piping components should be installed by qualified personnel according to current Pro-Flex installation instructions and applicable fuel-gas codes.
Important Ordering Notes
- PFVT-1206 is designed for 1/2" Pro-Flex CSST.
- PFVT-3406 is designed for 3/4" Pro-Flex CSST.
- Both models include a direct connect valve.
- Confirm the nominal CSST tubing size before ordering.
- Confirm the appliance or downstream connection requirements.
- Verify compatibility with the applicable Pro-Flex CSST system.
- Position the valve where it remains accessible as required by the installation.
- Follow current Pro-Flex installation instructions and applicable fuel-gas codes.
- Installation should be completed by qualified gas-piping personnel.
