Milwaukee
Milwaukee Tool EXACT 1" Punch
- SKU:
- MLW49-16-2665
- Availability:
- Usually Ships Same Day
- Weight:
- 0.21 LBS
Description
DUTY®
1 in Conduit
EXACT Punch
Make the opening for 1 in conduit with a size-matched EXACT punch and die setup.
Product Overview
The 1 in conduit rating differs from its nominal 1.362 in hole; check the fitting first.
Notches help grip the punch during threading; the cutting geometry aids slug removal.
- Conduit fit1 in conduit rating.
- Grip notchesGrip while threading.
- Visible sizingLarge size markings.
- Slug removalHelps clear the slug.
Technical Specifications
- Conduit size
- 1 in
- Nominal hole
- 1.362 in
- Matching die
- 49-16-2664
- Draw stud
- 3/4 in
- Punch grip
- Notched
- Spacers
- Not required for EXACT
Choose the Correct Fit
Pair this punch with die 49-16-2664. For the 2676-20 tool, the manual lists 49-16-2681 as a matching standard draw stud.
Use the thickness limit for the complete tool and accessory combination. Do not transfer the 10-ton tool rating to a different knockout tool.
Installation & Care
Remove the battery before setup. Drill the correct pilot, engage the threads fully and hand-tighten the punch and die securely.
Keep hands clear during the cut and punch one layer at a time. Discard damaged accessories and remove the slug before reuse.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need a knockout match? Tell Willy the conduit size, material, thickness and knockout-tool model.
Important Product Questions
Is the hole diameter the same as the conduit size?
No. The manual lists a 1.362 in nominal hole for this 1 in conduit punch. Confirm the fitting requires that opening.
What thickness can the setup punch?
The 2676-20 10-ton tool manual lists 10 gauge mild steel and 12 gauge stainless for this size. Other tools may have lower limits.
Can I use the punch without its die?
Use the matching 49-16-2664 die and a compatible draw stud. The die supports the cut and is a separate component; the punch alone is not a complete setup.
