Milwaukee
Milwaukee Tool Adjustable Hole Cutter
- SKU:
- MLW49-56-0320
- Availability:
- Usually Ships Same Day
- Weight:
- 0.80 LBS
Description
DUTY®
2–7" Adjustable
Hole Cutter
An adjustable cutter for 2- to 7-inch holes in drywall and ceiling tile, set in 1/4-inch increments with a tool-free QUIK-LOK arbor and a reusable dust shield.
Product Overview
Choose a listed quarter-inch setting; the cutter is not continuously adjustable.
Cut drywall or ceiling tile up to 1 in thick; check for hidden services before making the opening.
- Indexed hole sizesQuarter-inch size settings.
- Tool-free adjustmentTool-free QUIK-LOK setting.
- Readable scaleLaser-etched size markings.
- Reusable dust shieldSpring-loaded collar.
Technical Specifications
- Hole diameter
- 2–7 in
- Size increment
- 1/4 in
- Material thickness
- Up to 1 in
- Materials
- Drywall / ceiling tile
- Adjustment
- Tool-free QUIK-LOK
- Shield collar
- Spring-loaded
Choose the Correct Fit
Confirm that the required opening matches a quarter-inch increment within the two- to seven-inch range.
Inspect the wall or ceiling for electrical wiring, piping and other hidden services before drilling.
Installation & Care
Set and secure the cutter according to the instructions, fit the shield and support the work to control the cut.
Disconnect drill power before adjustment or blade service. Use the specified replacement blades and pilot bit and inspect the assembly before use.
Small Details. Big Jobsite Energy.
Get set. Stay focused. Make your next move count.
THE NEXT JOB.
Ask Willy:
Need help choosing? Tell Willy your material, required size and working clearance so the GetPipe team can check the fit.
Important Product Questions
Can I cut an exact diameter between the quarter-inch marks?
The stated adjustment is in 1/4-inch increments. Use a different suitable cutter if the required opening falls between those settings.
Is it also a metal or wood hole cutter?
The exact product’s stated materials are drywall and ceiling tile. Do not apply those limits to metal, wood or other board products without manufacturer approval.
Which service parts should I check when the cut deteriorates?
Inspect the cutting blades and pilot bit. The exact source identifies replacement blade and pilot-bit kit 49-56-0290; disconnect power before servicing.
