Midland Chrome Plated Mini Brass Ball Valve (F x F)
- Availability:
- Allow 2-3 Days to Ship
- Weight:
- 0.00 LBS
Description
Midland Chrome Plated Mini Brass Ball Valve (F x F)
Midland Chrome Plated Mini Brass Ball Valves provide dependable quarter-turn shutoff in compact plumbing, instrumentation, pneumatic, OEM, and general-purpose fluid handling systems.
Manufactured from solid brass with a corrosion-resistant chrome-plated finish, these valves feature female NPT threaded connections on both ends and a compact flag handle for quick manual operation. Available in 1/4", 3/8", and 1/2" sizes, the miniature design makes them well suited for installations where space and handle clearance are limited.
Product Highlights
- Midland chrome-plated mini brass ball valve
- Female NPT x Female NPT threaded connections
- Compact quarter-turn flag handle
- Solid brass body construction
- Corrosion-resistant chrome-plated finish
- Designed for dependable on/off shutoff
- Compact profile for space-restricted installations
- Suitable for water, air, oil, and general-purpose service
- Ideal for plumbing, instrumentation, pneumatic, and OEM applications
- Available in 1/4", 3/8", and 1/2" sizes
Technical Specifications
| Product Type | Mini Ball Valve |
|---|---|
| Brand | Midland |
| Body Material | Brass |
| Finish | Chrome-Plated |
| Connection Type | Female NPT x Female NPT |
| Connection Configuration | F x F |
| Handle Style | Flag Handle |
| Operation | Quarter Turn |
| Available Sizes | 1/4", 3/8", and 1/2" |
| Primary Function | Manual On/Off Flow Control |
| Typical Media | Water, Air, Oil, and Other Compatible General-Purpose Media |
| Typical Applications | Plumbing, Instrumentation, Pneumatic, OEM, and Compact Fluid Systems |
Valve Configuration
Female NPT Inlet
The inlet accepts a compatible male NPT pipe, nipple, fitting, manifold connection, or equipment port.
Female NPT Outlet
The outlet also uses a female NPT connection, creating a straightforward female-to-female inline valve configuration.
Compact Flag Handle
The low-profile flag handle provides positive quarter-turn operation while minimizing the clearance required around the valve.
Construction Details
The valve body is manufactured from solid brass to provide dependable strength, durability, and corrosion resistance in compatible fluid handling applications.
A chrome-plated exterior finish helps protect the body while providing a durable surface for commercial, industrial, and OEM service.
The compact flag handle rotates approximately 90 degrees between fully open and fully closed positions, allowing fast manual shutoff in installations where a conventional lever handle may not fit.
Why Choose a Mini Ball Valve?
Compact Installation
- Small overall footprint
- Low-profile flag handle
- Useful in confined spaces
- Easy integration into equipment
- Ideal for compact piping assemblies
Fast Manual Shutoff
- Quarter-turn operation
- Quick open and closed positioning
- Simple manual control
- Designed for isolation service
- No external actuator required
Available Sizes
1/4"
Compact size for small plumbing, pneumatic, instrumentation, and OEM fluid handling applications.
3/8"
Intermediate size suitable for compact equipment, utility, air, and general-purpose fluid systems.
1/2"
Larger available size for compatible plumbing, mechanical, pneumatic, and fluid transfer applications.
Typical Applications
Instrumentation & Pneumatic
- Instrument lines
- Pneumatic circuits
- Equipment isolation
- Machine utility lines
- Compact control assemblies
Plumbing & OEM
- Compact plumbing assemblies
- OEM equipment
- Small fluid circuits
- Service shutoff points
- Space-restricted installations
Need help confirming valve size, the Female NPT x Female NPT (F x F) configuration, or whether this Midland chrome-plated mini brass ball valve is right for your application? The GetPipe.com Team can help before you order.
Email the GetPipe.com Team Visit Quick SupportFrequently Asked Questions
What connection configuration does this valve use?
The valve uses female NPT threaded connections on both ends, commonly identified as F x F.
What material is the valve body made from?
The supplied product information identifies solid brass construction with a chrome-plated finish.
What type of handle does it use?
The valve uses a compact flag handle for quarter-turn manual operation.
What sizes are available?
The supplied product information identifies 1/4", 3/8", and 1/2" sizes.
What media can this valve be used with?
The supplied product information identifies water, air, oil, and general-purpose service. Always verify material, pressure, and temperature compatibility for the intended application.
Why use a flag handle?
A flag handle requires less operating clearance than many conventional lever handles, making it useful in compact or enclosed installations.
Is this a quarter-turn valve?
Yes. The handle rotates approximately 90 degrees between the fully open and fully closed positions.
What should I verify before ordering?
Confirm valve size, female NPT connection requirements, operating pressure, temperature, intended media, and available handle clearance.
Important Ordering & Installation Notes
- This listing is for Midland Chrome Plated Mini Brass Ball Valves with F x F connections.
- Available sizes are 1/4", 3/8", and 1/2".
- Confirm the required nominal valve size before ordering.
- Both ends use female NPT threaded connections.
- Verify brass and chrome-plated construction are compatible with the intended service media.
- Confirm system pressure and operating temperature requirements before installation.
- Use appropriate thread sealant or PTFE tape where permitted on NPT connections.
- Apply installation torque to proper wrenching surfaces rather than the flag handle.
- Avoid excessive tightening that could damage the valve body or threaded connections.
- Verify adequate clearance for complete quarter-turn flag-handle movement.
- Support connected piping to prevent excessive mechanical loading on the valve.
- Check threaded connections for leakage after installation.
- Use the valve primarily in the fully open or fully closed position for isolation service.
- Fully isolate and depressurize the system before servicing or replacing the valve.
- Follow applicable piping requirements and Midland manufacturer recommendations.
