Lead-Free Brass Quarter-Turn Hose Bib
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Lead-Free Brass Quarter-Turn Hose Bib
Charman lead-free brass quarter-turn hose bibs provide convenient hose connection and fast on/off flow control for compatible residential and commercial water-service applications. The family includes standard and no-kink configurations with MIP or FIP inlets and a 3/4" male hose thread outlet.
Select the required inlet connection and configuration from the product options above. The selected variation determines the Charman item number, online selling price, weight, cost, and connection-specific product information.
Product Highlights
- Heavy-duty brass construction
- Lead-free product family
- Quarter-turn operation
- 3/4" male hose thread outlet
- Available with MIP or FIP inlet connections
- No-kink configurations available
- Corrosion-resistant construction
- Designed for residential and commercial use
- Inner package quantity: 12
- Master package quantity: 72
Technical Specifications
| Product Type | Quarter-Turn Hose Bib |
|---|---|
| Body Material | Heavy-Duty Brass |
| Lead-Free | Yes |
| Operation | Quarter Turn |
| Inlet Connections | Male Iron Pipe (MIP) or Female Iron Pipe (FIP) |
| Outlet Connection | 3/4" Male Hose Thread (MHT) |
| Configurations | Standard and No-Kink |
| Application | Residential & Commercial Use |
| Packaging | 12 Inner / 72 Master |
| Manufacturer | Charman Manufacturing, Inc. |
Quarter-Turn & No-Kink Design
The quarter-turn handle provides quick open/close operation. Charman's no-kink configurations are designed to provide a hose connection layout intended to reduce hose interference at the outlet. Select the standard or no-kink configuration and inlet thread type required for the installation.
Common Applications
Residential
- Exterior hose connections
- Utility and wash-down connections
- Garden-hose connections
- General water-service outlets
Commercial
- Building maintenance connections
- Mechanical and utility areas
- Wash-down service
- Commercial hose connections
Product Resources
Review the Charman Hose Bibbs specification sheet for manufacturer-published part numbers, connection configurations, packaging quantities, and product features.
Need Help Selecting a Charman Quarter-Turn Hose Bib?
Our industrial PVF specialists can help confirm inlet size, MIP or FIP connection type, standard or no-kink configuration, hose connection requirements, and product availability.
Frequently Asked Questions
What outlet connection do these hose bibs use?
All five configurations use a 3/4" male hose thread outlet.
What inlet connections are available?
The family includes 1/2" and 3/4" MIP configurations plus 1/2" and 3/4" FIP configurations.
What does no-kink mean?
Charman identifies four of the five configurations as no-kink hose bibs. The design is intended to provide a hose connection layout that helps reduce hose interference at the outlet.
Are these quarter-turn hose bibs?
Yes. Charman identifies this family as quarter-turn hose bibs for fast on/off operation.
Are these lead free?
Yes. Charman identifies this hose-bib family as lead free in its published specification sheet.
How are they packaged?
Charman publishes an inner package quantity of 12 and a master package quantity of 72 for each configuration.
Important Ordering Notes
- Select the required inlet size, MIP or FIP connection, and standard or no-kink configuration before adding the product to your cart.
- The selected variation determines the Charman item number, price, weight, and cost.
- Confirm connection type, water-service compatibility, pressure, temperature, and applicable code requirements before installation.
- Use approved thread sealant where required for the pipe-thread inlet connection.
- Installation should be completed by qualified personnel.
