Charman Inc.
Gas Connector End Fittings - Flare x FIP
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Gas Connector End Fittings - Flare x FIP
Charman Inc Gas Connector End Fittings provide a threaded transition between compatible flare-style gas connector connections and female iron pipe connections. This Flare x FIP family includes multiple flare and FIP size combinations for matching different gas connector and piping configurations.
Each fitting combines a flare connection on one end with a female threaded pipe connection on the other. Available configurations range from 3/8" flare connections through 15/16" flare connections, with 3/8", 1/2", and 3/4" FIP options depending on the fitting selected.
Product Highlights
- Gas connector end fitting
- Flare x FIP connection configuration
- Female iron pipe threaded connection
- Multiple flare sizes available
- Multiple FIP sizes available
- Designed for compatible gas connector installations
- Provides a transition from flare connection to female pipe thread
- Six connection configurations available on one listing
- Compact fitting design for gas connector assemblies
Technical Specifications
| Product Type | Gas Connector End Fitting |
|---|---|
| Brand | Charman Inc |
| Connection Style | Flare x FIP |
| Flare Sizes | 3/8", 1/2" and 15/16" |
| FIP Sizes | 3/8", 1/2" and 3/4" |
| Available Configurations | 3/8" Flare x 3/8" FIP, 3/8" Flare x 1/2" FIP, 1/2" Flare x 3/8" FIP, 1/2" Flare x 1/2" FIP, 15/16" Flare x 1/2" FIP and 15/16" Flare x 3/4" FIP |
| Primary Application | Gas Connector End Connections |
Understanding Flare x FIP Connections
The flare end is designed to connect with a compatible flare-style gas connector connection. The FIP end provides a female threaded pipe connection for mating with a compatible male pipe thread.
Because several connection-size combinations are available, confirm both the flare size and FIP size required for the installation before selecting a fitting.
Available Connection Configurations
- 3/8" Flare x 3/8" FIP - FF01
- 3/8" Flare x 1/2" FIP - FF02
- 1/2" Flare x 3/8" FIP - FF20
- 1/2" Flare x 1/2" FIP - FF21
- 15/16" Flare x 1/2" FIP - FF50
- 15/16" Flare x 3/4" FIP - FF51
Selecting the Correct End Fitting
Confirm the Flare Size
Match the fitting's flare connection to the compatible gas connector connection. Available flare sizes in this listing include 3/8", 1/2", and 15/16".
Confirm the FIP Size
Match the female pipe-thread connection to the compatible male pipe thread in the gas piping or equipment connection. Available FIP sizes include 3/8", 1/2", and 3/4".
Common Applications
Gas Connector Assemblies
- Flexible gas connector installations
- Gas appliance connections
- Replacement connector fittings
- Gas equipment connections
- Connector assembly repairs and maintenance
Connection Transitions
- Flare-to-pipe-thread transitions
- Different flare and pipe-thread sizes
- Gas connector replacement projects
- Equipment connection changes
- New gas connector installations
Ask Willy: Need Gas Connector Fitting Help?
Use the Charman Inc End Fittings for Gas Connectors catalog to compare available fitting styles, connection sizes, and configurations before ordering.
Installation & Selection Guidance
- Confirm the required flare connection size before ordering.
- Confirm the required FIP connection size before ordering.
- Verify that the FIP end mates with a compatible male pipe thread.
- Verify compatibility with the gas connector being installed.
- Inspect the fitting and sealing surfaces before installation.
- Do not install fittings with damaged threads or flare surfaces.
- Use connection and sealing practices appropriate for the gas piping system.
- Do not overtighten connections.
- Support connected piping and equipment as required.
- Leak-test completed gas connections before placing equipment into service.
- Follow applicable fuel-gas codes, equipment instructions, and local requirements.
- Installation should be performed by qualified personnel familiar with gas piping systems.
Product Selection Considerations
Flare Connection
Flare size is not interchangeable. Confirm whether the installation requires a 3/8", 1/2", or 15/16" flare connection before choosing the fitting.
Pipe Thread Connection
The FIP connection must match the corresponding male threaded connection. Confirm whether the installation requires 3/8", 1/2", or 3/4" FIP.
Need Help Selecting a Gas Connector End Fitting?
Our PVF specialists can help review your gas connector flare size, pipe-thread size, fitting configuration, and installation requirements before you order.
Frequently Asked Questions
What type of fittings are included in this listing?
This listing includes gas connector end fittings with a flare connection on one end and a female iron pipe connection on the other.
What flare sizes are available?
Available flare sizes are 3/8", 1/2", and 15/16", depending on the selected fitting.
What FIP sizes are available?
Available female iron pipe sizes are 3/8", 1/2", and 3/4", depending on the selected fitting.
What does FIP mean?
FIP identifies a female threaded pipe connection designed to mate with a compatible male threaded pipe connection.
Are the flare and FIP sizes always the same?
No. Several variants transition between different flare and FIP sizes. Select the exact configuration required for the installation.
Which fitting has a 3/8" flare x 3/8" FIP connection?
SKU FF01 provides a 3/8" flare x 3/8" FIP configuration.
Which fitting has a 1/2" flare x 1/2" FIP connection?
SKU FF21 provides a 1/2" flare x 1/2" FIP configuration.
Which fittings use a 15/16" flare connection?
FF50 provides a 15/16" flare x 1/2" FIP connection, while FF51 provides a 15/16" flare x 3/4" FIP connection.
Should gas connections be leak-tested?
Yes. Completed gas connections should be leak-tested using an appropriate method before the connected equipment is placed into service.
Where can I compare additional gas connector end fittings?
Use the Charman Inc End Fittings for Gas Connectors catalog linked in the Willy section to review additional fitting information and configurations.
Important Ordering Notes
- This listing is for Flare x FIP gas connector end fittings.
- Six connection configurations are included.
- Confirm both the flare size and FIP size before ordering.
- The flare connection and pipe-thread connection are not interchangeable.
- FF01 is 3/8" Flare x 3/8" FIP.
- FF02 is 3/8" Flare x 1/2" FIP.
- FF20 is 1/2" Flare x 3/8" FIP.
- FF21 is 1/2" Flare x 1/2" FIP.
- FF50 is 15/16" Flare x 1/2" FIP.
- FF51 is 15/16" Flare x 3/4" FIP.
- Review the linked Charman Inc End Fittings for Gas Connectors catalog for additional product information.
- Installation should comply with applicable fuel-gas codes and local requirements.
- Gas connections should be installed and tested by qualified personnel.
