Full Face PTFE (Teflon) Gasket 1/16" Thick Class 150
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
150# Teflon (PTFE) Full Face Gaskets - 1/16" Thick
150# Teflon (PTFE) Full Face Gaskets are designed to provide complete flange coverage and dependable sealing performance in applications requiring thinner-profile gasket material and superior chemical resistance. Manufactured from high-quality virgin PTFE material, these gaskets offer excellent resistance to aggressive chemicals, acids, and solvents while maintaining a clean, non-contaminating seal.
The full face design distributes load evenly across the entire flange surface, helping reduce the risk of leakage and flange distortion. The 1/16" thickness allows for improved flange alignment and reduced creep while still providing reliable sealing performance. PTFE gaskets are inherently inert and ideal for use in food processing, pharmaceutical, water treatment, and chemical processing systems where purity and corrosion resistance are critical.
- Style: Full Face Gasket
- Flange Rating: 150#
- Material: PTFE (Teflon)
- Construction: Virgin PTFE Sheet
- Thickness: 1/16"
- Compliance: FDA Approved
- Service: Chemical, Food Processing, Water Treatment
- Key Feature: Full Coverage Sealing & Chemical Resistance
Need Help Matching Flange Dimensions?
Use the dimensional PDF below to confirm gasket sizing, bolt hole layout, and Class 150 flange requirements before ordering.
