Charman Inc.
150# Galvanized Malleable Iron Reducing Tee
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
150# Galvanized Malleable Iron Reducing Tee
150# galvanized malleable iron reducing tees create a 90-degree branch connection while transitioning between different nominal pipe sizes. The three female NPT openings allow a threaded piping system to divide, combine, or reduce flow paths within one compact fitting.
Select the required connection combination from the product options above. Variations are listed in the same connection order shown in the Charman item description. The selected variation determines the Charman item number, online selling price, weight, cost, and other size-specific product information.
Product Highlights
- 150# Class galvanized malleable iron construction
- Three female NPT threaded connections
- Creates a 90-degree branch connection
- Provides one or more reduced connection sizes
- Combines branching and size reduction in one fitting
- Galvanized finish provides added corrosion resistance
- Compatible with galvanized steel pipe and threaded pipe nipples
- Broad range of reducing combinations for commercial and industrial piping
Technical Specifications
| Material | Galvanized Malleable Iron |
|---|---|
| Pressure Class | 150# / Class 150 |
| Connection | Female NPT x Female NPT x Female NPT |
| Configuration | Reducing Tee |
| Branch Angle | 90 Degrees |
| Thread Standard | ASME B1.20.1 |
| Dimensional Standard | ANSI/ASME B16.3 |
| Finish | Galvanized |
| Fitting Type | Threaded Reducing Pipe Tee |
| Manufacturer | Charman Manufacturing |
| Available Combinations | Multiple run and branch reductions through 4-inch nominal size |
How a Reducing Tee Works
The straight-through openings continue the primary pipe run, while the third opening creates a 90-degree branch. Depending on the selected variation, the run, branch, or both may be reduced. This allows the fitting to create a branch and change nominal pipe size without requiring a separate reducer or bushing.
Understanding the Size Order
Reducing tee dimensions can vary by configuration. Select the exact size combination shown in the product options and confirm the connection order against your piping layout before ordering. Some Charman variations use three listed dimensions, while certain larger configurations are supplied under a shortened two-size description.
Common Applications
Plumbing and Mechanical Systems
- Reduced branch takeoffs
- Mechanical-room piping
- Galvanized steel pipe installations
- Water and utility piping
- Valve and equipment branches
- General repair and maintenance
Industrial and Utility Service
- Industrial process piping
- Compressed-air systems
- Outdoor and damp-location piping
- Oil and petroleum piping
- Equipment and skid piping
- Approved low-pressure steam service
Product Resources
Review the Charman product catalog, galvanized malleable iron specifications, and manufacturer warranty information before installation.
Need Help Selecting a Galvanized Reducing Tee?
Our industrial PVF specialists can help confirm the run sizes, branch size, connection order, pressure class, thread type, service conditions, material compatibility, and product availability.
Frequently Asked Questions
What is a galvanized reducing tee used for?
A reducing tee creates a 90-degree branch while connecting threaded piping components of different nominal sizes.
Are all three openings female threaded?
Yes. The fitting has three female NPT openings.
How is a reducing tee different from an equal tee?
An equal tee has the same nominal size at all three openings. A reducing tee has one or more smaller connection sizes.
How should I read the listed sizes?
Select the exact connection combination shown and confirm the order against your required piping layout. Reducing tee configurations can differ depending on which opening is reduced.
What pressure class is this fitting?
This galvanized malleable iron reducing tee is manufactured as a 150# or Class 150 threaded fitting.
Can it be used with galvanized steel pipe and fittings?
Yes. It is designed for compatible NPT-threaded galvanized pipe, nipples, valves, fittings, and approved equipment connections.
Does the galvanized finish improve corrosion resistance?
Yes. The galvanized finish provides added corrosion resistance compared with an unfinished black fitting, although suitability still depends on the environment, piping media, temperature, and application.
Should thread sealant be used?
Use an approved pipe-thread sealant or thread tape on the male NPT components entering each opening, selected for the piping media, pressure, temperature, applicable codes, and manufacturer recommendations.
Important Ordering Notes
- Select the exact connection combination before adding the product to your cart.
- The selected variation determines the Charman item number, price, weight, and cost.
- Confirm all run and branch sizes before ordering.
- Confirm the listed connection order against the required piping configuration.
- Use an approved thread sealant suitable for the piping media and operating conditions.
- Do not overtighten the fitting, as excessive force can damage the threads or fitting body.
- Confirm pressure, temperature, media compatibility, corrosion exposure, and application requirements before installation.
- Support connected piping properly to avoid excessive mechanical stress on the tee.
- Installation should be completed by qualified personnel and comply with applicable codes and standards.
- Manufacturer warranty coverage is subject to the terms, limitations, and exclusions in the linked warranty document.
