Description
Lead-Free Bronze Cross
Lead-free bronze threaded crosses provide four equal-size female NPT threaded openings arranged at 90-degree angles for intersecting pipe runs and branch connections.
Select the required nominal pipe size from the product options above. The selected variation determines the Charman item number, online selling price, weight, cost, and size-specific product information.
Product Highlights
- Lead-free bronze construction
- Four-way equal cross configuration
- Female NPT connections on all four openings
- Provides intersecting and branch connections from one compact fitting
- Corrosion-resistant bronze construction for threaded piping systems
- Available in nominal pipe sizes from 1/8" through 2"
Technical Specifications
| Material | Lead-Free Bronze |
|---|---|
| Configuration | Equal Cross |
| Connections | Female NPT x Female NPT x Female NPT x Female NPT |
| Manufacturer | Charman Manufacturing, Inc. |
| Available Sizes | 1/8" through 2" |
How a Threaded Cross Works
A threaded cross joins four compatible male-threaded pipe, nipple, fitting, valve, or equipment connections at 90-degree angles. All four openings are the same nominal pipe size, making the fitting useful for intersecting runs or multiple branch connections in a compact piping layout.
Common Applications
Plumbing & Mechanical
- Water piping
- Equipment connections
- Branch piping
- Mechanical-room piping
Commercial & Industrial
- Threaded process piping
- Utility piping
- Intersecting pipe runs
- Maintenance and repair installations
Need Help Selecting a Lead-Free Bronze Cross?
Our industrial PVF specialists can help confirm nominal pipe size, thread type, material compatibility, service conditions, and product availability.
Frequently Asked Questions
What does a bronze cross do?
It joins four compatible male-threaded piping connections at 90-degree angles, allowing intersecting runs or multiple branches from one fitting.
What connections does this cross use?
It uses female NPT threaded connections on all four openings.
Are all four openings the same size?
Yes. Each selected variant has four equal-size female NPT openings.
What does LF mean in the Charman description?
LF identifies the lead-free version of the bronze fitting.
Important Ordering Notes
- Select the required nominal pipe size before adding the product to your cart.
- The selected variation determines the Charman item number, price, weight, and cost.
- Confirm all four female NPT connection sizes before ordering.
- Use an approved thread sealant appropriate for the piping media and service conditions.
- Confirm pressure, temperature, media compatibility, and applicable code requirements before installation.
