Charman Inc.
Large Diameter Galvanized Steel Precut Pipe Nipple, Schedule 40, Threaded Both Ends
- Availability:
- Usually in Stock – Ships Quickly
- Weight:
- 0.00 LBS
Description
Large Diameter Galvanized Steel Precut Pipe Nipple, Schedule 40, Threaded Both Ends
Large diameter galvanized steel precut pipe nipples provide ready-to-install male NPT connections for commercial, industrial, plumbing, HVAC, mechanical, compressed-air, gas, oil, water, and general-purpose piping systems. These Schedule 40 threaded precuts are offered in selected 2-1/2", 3", and 4" nominal pipe sizes with extended lengths for larger piping assemblies and a corrosion-resistant galvanized finish.
Select the required nominal pipe size and overall precut length from the product options. Standard online variations run from 18" through 72", depending on pipe size. Need a different length or a nipple threaded on only one end? Use the custom request form below and the GetPipe.com team will review your requirements.
Product Highlights
- Schedule 40 galvanized steel construction
- Male NPT threads on both ends for standard product variations
- Conforms to ASTM A53 pipe and ASTM A733 steel nipple requirements
- NPT threads conform to ASME B1.20.1
- Large diameter nominal pipe sizes: 2-1/2", 3", and 4"
- Precut lengths from 18" through 72", depending on selected pipe size
- Suitable for compatible gas, air, water, oil, mechanical, and general-purpose piping systems
Technical Specifications
Available Sizes and Lengths
Online large-diameter variations include 2-1/2" in 18", 24", 30", 36", 48", and 60" lengths; 3" in 18", 24", 30", 36", 48", 60", and 72" lengths; and 4" in 18", 24", 30", 36", 48", and 60" lengths. Custom-cut lengths are also available by request.
Selecting a size may change the available length choices, price, weight, and item number. Refer to the product variations for the exact combinations currently offered online.
Common Applications
Commercial and Mechanical
- Mechanical rooms and equipment connections
- HVAC and building-service piping
- Valve, union, tee, and fitting connections
- Maintenance and repair assemblies
Industrial and General Piping
- Compressed-air piping
- Compatible gas and oil systems
- Water and general-purpose piping
- Fabrication and equipment assemblies
Application suitability, pressure limits, temperature limits, joining methods, codes, corrosion requirements, and system compatibility must be verified by the purchaser, installer, or system designer before use.
Product Resources
Use the documents below to review the manufacturer catalog, technical specifications, and complete warranty terms.
Ask WillyNeed help selecting the right large diameter galvanized steel precut pipe nipple?
Our team can help with large diameter Schedule 40 galvanized pipe nipples, long precut lengths, threaded pipe fittings, custom lengths, large-quantity requests, and hard-to-find PVF products.
Frequently Asked Questions
What does Schedule 40 mean?
Schedule 40 identifies the pipe wall schedule used for these galvanized steel nipples. Actual wall thickness varies by nominal pipe size.
Are these pipe nipples threaded on both ends?
Yes. Standard variations are male NPT threaded on both ends. Threaded-one-end and custom-length requests can be submitted through the custom quote form.
What sizes are available?
This online large-diameter family includes 2-1/2", 3", and 4" nominal pipe sizes. Standard online precut lengths run from 18" through 72", depending on the selected pipe size, and custom-cut lengths are available by request.
How is the overall nipple length measured?
Pipe nipple length is generally specified as the overall end-to-end length, including the threaded portions. Verify the required overall length before ordering.
Can I request a nonstandard length?
Yes. Use the Request a Custom Pipe Nipple form to submit the pipe size, overall length, thread style, quantity, and project details for review.
Important Ordering Notes
- Verify nominal pipe size, overall length, thread style, quantity, and system compatibility before ordering.
- Available options, prices, weights, and lead times may vary by selected variation.
- Longer precut lengths may require oversize ground handling or freight service; the final shipping method depends on the selected variation, quantity, destination, and total order.
- Custom-cut and specially fabricated items are non-cancellable and non-returnable once submitted and processed.
- The manufacturer warranty is subject to the terms, limitations, and exclusions in the linked warranty document.
