150# Galvanized Side Outlet 90° Elbow
- SKU:
- 34OE
- Availability:
- Usually Ships Same Day
- Weight:
- 0.00 LBS
Description
150# Galvanized Side Outlet 90° Elbow
ASC 150# Galvanized Side Outlet 90° Elbows combine a 90-degree directional change with an additional side outlet, providing three threaded connection points in one compact fitting.
Manufactured from malleable iron with a hot-dip galvanized finish, this Class 150 fitting is designed for compatible threaded piping systems requiring both a change in direction and an additional branch connection.
Product Highlights
- ASC galvanized malleable iron fitting
- Class 150 fitting design
- 90° elbow with side outlet
- Female NPT threaded connections
- Hot-dip galvanized finish
- UL Listed and FM Approved
Technical Specifications
| Product Type | Side Outlet 90° Elbow |
|---|---|
| Brand | ASC |
| SKU Series | 34OE |
| Material | Malleable Iron |
| Finish | Hot-Dip Galvanized |
| Fitting Class | 150# |
| Connection Type | Female NPT Threaded |
| Configuration | 90° Elbow with Side Outlet |
| Approvals | UL Listed / FM Approved |
| Applicable Standards | ASTM A197 / ASTM A153 / ASME B16.3 / ASME B1.20.1 |
Construction Details
The ASC side outlet 90° elbow is manufactured from malleable iron with a hot-dip galvanized coating for additional corrosion protection in compatible piping environments.
The fitting combines a standard 90° directional change with an additional side outlet, allowing three piping connections to meet at one compact fitting.
NPT threaded connections provide compatibility with properly sized threaded pipe, nipples, valves, and other suitable system components.
Side Outlet Design & Typical Applications
Side Outlet Design
- 90° directional change
- Additional side branch
- Three threaded openings
- Galvanized exterior finish
- Malleable iron construction
Typical Applications
- Industrial piping systems
- Utility piping
- Construction piping
- Branch piping layouts
- General threaded piping
Installation & Selection Considerations
- Confirm all connection sizes.
- Verify the 90° branch layout.
- Confirm galvanized compatibility.
- Use compatible thread sealant.
- Avoid over-tightening connections.
Use the supplied pipe chart to review common pipe diameters and wall thicknesses when confirming compatible piping for this galvanized side outlet elbow.
Need Help Selecting a 150# Galvanized Side Outlet 90° Elbow?
Need help confirming connection sizes, galvanized construction, fitting class, or the correct side outlet configuration for your piping layout? The GetPipe.com Team can help.
Frequently Asked Questions
What is a side outlet 90° elbow?
It combines a 90° directional change with an additional side outlet, providing three connection points within one fitting.
What material is this fitting?
The fitting is manufactured from malleable iron with a hot-dip galvanized finish.
What type of connections does it use?
The fitting uses female NPT threaded connections for compatible threaded piping components.
Why is the fitting galvanized?
The galvanized coating provides additional surface corrosion protection compared with an unfinished black malleable iron fitting.
What does 150# mean?
150# identifies the fitting class and should not be interpreted by itself as a universal 150 PSI working-pressure rating.
Is this fitting UL Listed and FM Approved?
Yes. ASC identifies its Class 150 galvanized side outlet 90° elbows as UL Listed and FM Approved.
What thread standard is used?
The NPT threads conform to ASME B1.20.1 for compatible threaded piping connections.
What should I confirm before ordering?
Confirm all connection sizes, the 90° side outlet configuration, galvanized finish, fitting class, and compatibility with the intended piping system.
Important Ordering & Installation Notes
- Confirm all connection sizes.
- Verify the side outlet orientation.
- Confirm galvanized construction.
- Use compatible thread sealant.
- Follow proper installation practices.
